Multivitamin/multimineral complexes are the most common dietary supplements. Unlike minerals in foods that are incorporated in bioorganic structures, minerals in dietary supplements are typically in an inorganic form. These minerals can catalyze the generation of free radicals, thereby oxidizing antioxidants during digestion. Here we examine the ability of a matrix consisting of an amino acid and non-digestible oligosaccharide (AAOS) to blunt metal-catalyzed oxidations. Monitoring of ascorbate radical generated by copper shows that ascorbate is oxidized more slowly with the AAOS matrix than with copper sulfate. Measurement of the rate of oxidation of ascorbic acid and Trolox® by catalytic metals confirmed the ability of AAOS to slow these oxidations. Similar results were observed with iron-catalyzed formation of hydroxyl radicals. When compared to traditional forms of minerals used in supplements, we conclude that the oxidative loss of antioxidants in solution at physiological pH is much slower when AAOS is present.
There is increasing interest by the public in nutrition, functional foods, and nutritional supplements. The nutritional supplement market in the United States is estimated to be over $1 × 1010 y-1 and growing . Although dietary supplements are not intended to substitute for a healthy variety of food, millions of people complement their daily food intake with dietary supplements to ensure the requisite intake of essential nutrients required for proper bodily functions and good health. Formulations of multivitamin supplements typically include oxidation-sensitive vitamins, such as vitamin C and E, as well as minerals, such as iron and copper, in the same formulation. Minerals can have limited solubility, depending on their exact form. In addition redox active transition metals, such as iron and copper, can serve as catalysts for the oxidation of organic compounds. For example, adventitious, trace levels of iron and copper in near-neutral phosphate buffer readily catalyze the oxidation of ascorbate [2, 3]. Ferric iron is a standard reagent used to oxidize tocopherols to their corresponding quinones . Thus, these metals could bring about the loss of antioxidants before absorption by the digestive system.
The rate of metal-catalyzed oxidations, e.g. by copper or iron ions, varies greatly with solubility and the ligand environment. In addition, the metal-catalyzed oxidation of ascorbate can lead to the oxidation of other substances in the solutions . In fact the combination of iron and ascorbate has long been used to oxidize organics; the combination of these two reagents is referred to as the Udenfriend system and is used to for the hydroxylation of alkanes, aromatics, and other oxidations [6, 7]. The combination of iron and ascorbate has also been used as a tool to initiate oxidations in cells, especially the oxidation of cellular structures that have unsaturated lipids . As might be predicted, the production of hydroxyl radical has been observed upon dissolution of supplement tablets containing ascorbate . Co-supplementation of ferrous salts with vitamin C can increase oxidative stress in the gastrointestinal tract, reviewed in . Thus, a challenge is to provide a multivitamin/multimineral formulation that facilitates solubilization of the minerals and at the same time blunts the propensity of redox active metals to catalyze unwanted oxidations.
Here we investigate the ability of the supporting matrix in supplemental minerals to minimize the metal-catalyzed oxidation of oxidation-sensitive vitamins, e.g. ascorbate and tocopherol. Fructose-based oligosaccharides, such as inulin, have been demonstrated to enhance the absorption of calcium, magnesium, iron, and zinc [11–13]. Intake of inulin is associated with positive health effects, including maintenance of bone structure  and bone mineral content [15, 16]. Here we examine the ability of this oligosaccharide in combination with amino acids (AAOS) to blunt metal-catalyzed oxidation of antioxidants.
5,5-Dimethylpyrroline-1-oxide (DMPO; CAS# 3317-61-1), 2',7'-dichlorodihydrofluorescein diacetate (CAS# 4091-99-0), and ascorbic acid (50-81-7) were from Sigma Chemical Co. (St. Louis, MO); Trolox® (53188-07-1) was from Aldrich (Milwaukee, WI). Cupric carbonate(CAS# 12069-69-1), copper sulfate (CAS# 7758-99-8), copper glycinate (CAS# 13479-54-4), ferrous sulfate (CAS# 13463-43-9), glycine (CAS# 56-40-6), L-aspartic acid (CAS# 56-84-8), copper gluconate (CAS# 527093), and inulin (molecular weight of approximately 5,000 Da, CAS# 9005-80-5) were from Spectrum Chemicals & Laboratory Products, (New Jersey).
2.2.1 The copper-AAOS system was prepared by suspending Cu carbonate with glycine or aspartic acid followed by inulin at final molar ratio 1:4:0.01. After stirring for 10 min at 80°C the mixture was dried in an oven. Absence of carbonate was confirmed with hydrochloric acid.
2.2.2 The iron-AAOS system was prepared by first dissolving FeSO4 (1 mol) in water; then NaOH was added to precipitate the iron. Glycine or aspartic acid (2 mol) was added to a suspension of the Fe-solids; the mixture was stirred and then dried in oven. To prepare the iron-AAOS matrix glycine or aspartic acid (1 mol) was suspended in water with the iron solids; then 0.01 mol of inulin was added. After heating at 80°C, the resulting mixture was dried in oven.
All EPR measurements were done using a Bruker ER-200 X-band EPR spectrometer. Samples (50 μL) in capillary tubes (0.5 mm i.d.) were examined at room temperature. EPR instrument settings were: (1) for ascorbate experiments - microwave frequency 9.71 GHz; center field 3472 G; scan rate 10 G/20 s; modulation amplitude 1.25 G; time constant 0.5 s; microwave power 10 mW; and instrument gain 2 × 106; (2) for DMPO spin trapping (hydrogen peroxide plus iron or copper) - microwave frequency 9.71 GHz; center field 3472 G; scan rate 100 G/100 s; modulation amplitude 1.25 G; time constant 0.5 s; microwave power 10 mW; instrument gain was 2 × 106; (3) for Trolox® experiments - microwave frequency 9.71 GHz; center field 3472 G; scan rate 60 G/50 s; mod amp 1.0 G; time constant 0.5 s; microwave power 20 mW; and instrument gain 2 × 106; and (4) for transition metals - microwave frequency 9.71 GHz; center field 3415 G; scan rate 1000 G/100 s; modulation amplitude 2.5 G; time constant 0.5 s; microwave power 102 mW; instrument gain varied for different samples from 1.0 × 103 to 3.2 × 105. Manganese in calcium oxide was used as a reference standard.
2',7'-Dichlorodihydrofluorescein diacetate was hydrolyzed in 20 mM NaOH at room temperature for 20 min to remove the acetate esters to produce 2',7'-dichlorodihydrofluorescein (DCFH2). Mineral stock solutions were prepared in de-ionized water. DCFH2 (200 μL of 90 μM in 20 mM carbonate buffer, pH 7.0) and 80 μL of mineral solution (100 μM in 20 mM carbonate, pH 7.0) were mixed in a standard UV-Vis cuvette. The reaction was initiated by addition of 20 μL of 0.3% H2O2 yielding a final concentration of 88 mM. Absorbance at 500 nm (ε500 = 59,500 M-1 cm-1  was monitored for 30 min.
When copper with different coordination environments or matrices was introduced into this system, the intensity of the EPR spectrum of the Trolox® radical varied with the environment. Copper sulfate produced a robust EPR signal of the Trolox® free radical; when gluconate was available to coordinate the copper, the EPR signal was reduced by about 15%; however, when copper was introduced in the AAOS matrix, the EPR signal intensity was reduced by approximately 50%, compared to CuSO4. This is consistent with the observations with ascorbate indicating that AAOS reduces the oxidative flux in the system.
Multivitamin/multimineral complexes are the most common dietary supplements. Besides quality ingredients and the amount of each ingredient in a product, bioavailability is a major concern. Unlike minerals in natural foods that are incorporated in bioorganic structures, minerals in dietary supplements are usually in an inorganic form: sulfates, chlorides, oxides etc. The ability of redox active metals to catalyze oxidations is dependent on the coordination environment of the metal. Here we have demonstrated that amino acid complexes of copper (glycinate or aspartate) hinder the catalytic ability of copper or iron compared to the sulfate form of these metals. However, including oligofructose in the matrix brought about an even greater decrease in ability of iron and copper to oxidize substances. Here we have clearly demonstrated that:
AAOS slows the iron catalyzed oxidation of ascorbate;
AAOS slows the copper catalyzed oxidation of ascorbate;
AAOS slows the copper catalyzed oxidation of Trolox®, a vitamin E analogue;
AAOS inhibits the formation of DMPO/ ‧ OH generated by the Fenton reaction;
AAOS slows the copper catalyzed oxidation of DCFH2, a widely used marker of oxidative flux.
Inulin appears to have many positive health effects [13, 29–33]. Our results suggest another positive effect of oligosaccharide in that AAOS offers significant advantages when included in the matrix for the formulation of dietary supplements.
Although not directly addressed in this research, it is reasonable to suggest that how multivitamin/multimineral supplements are formulated can influence the uptake of both the minerals and the vitamins. Here we monitored the oxidations initiated by the redox-active minerals; we not only observed the oxidation of both ascorbate (vitamin C) and Trolox® (a vitamin E analogue) by these minerals, but also surrogate indicators of oxidizing environments, DMPO and DCFH2. It can be hypothesized that the oxidations initiated by redox active forms of mineral supplements could also present an oxidative challenge to tissue upon ingestion. Thus, as always there are risks and benefits that need to be understood. Improved formulation of multivitamin/multimineral supplements could both decrease risks and increase benefits.
AR, AK, JI, and GB contributed to experimental design. AR and AK ran the experiments. GB, AR and AK contributed to the analysis of the data. AR and GB were principally responsible for writing the paper with assistance from JSI and AMK. All authors read and approved the final manuscript.
amino acid chelate; such as glycinate
amino acid oligosaccharide
electron paramagnetic resonance
